Hauslane UC-PS18SS-36 - Chef 36-in Ducted Stainless Steel Undercabinet Range Hood
Hauslane UC-PS18SS-36 - Chef 36-in Ducted Stainless Steel Undercabinet Range Hood
Regular price
$699.99 USD
Regular price
Sale price
$699.99 USD
Quantity
Couldn't load pickup availability
Precision sealed burner gas range tops are built hand crafted quality, high performance burners, and dedication to precision that will keep you cooking masterpieces for a lifetime. Manufacturer Delay
Features
- Four Accu-Heat™ sealed brass burners rated at 19,000 BTUs each, creates powerfully consistent heat (additional 25,000 BTUs sealed center burner on the MCR305/GSCR305 models)
- All burners turn down to a true simmer
- Porcelain-coated cast iron grates with center bridge gate provide a continuous cooking surface
- 8″ center 15,000 BTU BBQ Grill available (MCR302B2, GSCR302B2, GRT302B2)
- 8″ center 15,000 BTU Thermo-Griddle™ available (MCR302G2, GSCR302G2, GRT302G2)
Specifications
| Configuration | 6 Sealed Burners |
| Size | 36 |
| Burner Type | Sealed |
| Range Fuel | Gas |
| Utility Type | All Gas |
| Electrical Rating | Voltage: 120 VAC/60 Hz Max. Current: 0.5 AMP Breaker Size: 10 AMP |
| Shipping Weight | 210 lbs |
| Product Weight | 180 lbs |
| Shipping Dimensions | 40 W x 20 H x 32 D |
| Product Dimensions | 35-7/8 W x 8-1/4 H x 27-1/8 D |
| Max Current/Circuit Breaker Rating | Voltage: 120 VAC/60 Hz Max. Current: 0.5 AMP Breaker Size: 10 AMP |
| Wiring Type | 120 VAC, 3 Prong with dedicated ground |
| Gas Connections | Natural Gas: 1/2 NPT Male |
| 7 WC input pressure (max. allowable pressure | 1/2 psi), 4 WC Pressure Regulator provided |
| Liquid Propane | 1/2 NPT Male |
| 11 WC input pressure (max. allowable pressure | 1/2 psi), 10 WC Pressure Regulator provided |
| Cutout Dimension | Standard Installation: 34-15/16W x 23-1/8D. No bottom platform required. 9 min. clearance to drawers |
